How to start

Время чтения: 3 минут

Plugin development framework for PLAG

Prereqisits:

Qt 6.1.2 GCC (with CMake)
QtCreator 4.x
Bash
Git

Clone repo of main application:

git clone https://gitlab.com/c4rb0n_un1t/PLAG.git

Go into PLAG folder and clone framework for plugins development:

cd PLAG
git clone https://gitlab.com/c4rb0n_un1t/PLAGins.git

Go into PLAGins folder and run plugin solution generation script (from PLUGins folder):

cd PLAGins
./Scripts/generate_plugin_code.sh

With this script you can generate base for any plugin.

Let’s start with logic-only plugin – it will provide only C++ interface without GUI (we will add GUI later).

$ ./Scripts/generate_plugin_code.sh
Specify name of your plugin: TestLogic
Your plugin is graphical user interface for other plugin? (y/n) n
Are you planning to provide some of your plugin's functionality to other plugins? (y/n) y
Specify name of your plugin's interface (press Enter to use suggested name: ITestLogic):
Specify filename of your plugin's interface (press enter to use suggested name: i_test_logic.h):
[SUCCESS] Your generated plugin could be found in ./Plugins/TestLogic directory.
There is CMakeLists.txt file that could be opened with QtCreator.

Now, lets create plugin, that will provide GUI for our new TestLogic plugin:

$ ./Scripts/generate_plugin_code.sh
Specify name of your plugin: TestUI
Your plugin is graphical user interface for other plugin? (y/n) y
Your plugin will use:
1 - QML(recommended)
2 - QWidjets
Type option number: 1
Your plugin is graphical user interface of other plugin. Please, choose name of file that contains interface of that plugin:
0: icontactlist.h
1: idayplan.h
2: i_dev_plugin_info_data_extention.h
3: i_dev_project_manager_data_extention.h
4: i_habits_tracker_data_ext.h
5: i_habits_tracker.h
6: imusicplayer.h
7: i_music_player_track_data_extention.h
8: i_music_player_track_progress_data_extention.h
9: ipomodoromanager.h
10: ipomodorosettingsdataextention.h
11: iprojectmanager.h
12: i_test_logic.h
13: i_user_task_data_ext.h
14: i_user_task_date_data_ext.h
15: i_user_task_image_data_ext.h
16: i_user_task_notes_data_ext.h
17: i_user_task_pomodoro_data_ext.h
18: i_user_task_project_data_ext.h
19: i_user_task_repeat_data_ext.h
20: iusertaskscalendar.h
21: iworktimermodel.h
File index: 12
[SUCCESS] Your generated plugin could be found in ./Plugins/TestUI directory.
There is CMakeLists.txt file that could be opened with QtCreator.

Projects of TestLogic and TestUI plugins could be found in PLAGins/Plugins folder. Open these projects and project of main application in PLAG/Application with QtCreator.
